- Qn2,5 to Qn15
Usage
The KWZ series contact water meters are used to control water softeners and dosing pumps. The construction and connection dimensions comply with DIN ISO 4064.
The meters are suitable for horizontal installation and cold water up to 30°C. A roller counter allows the total water volume to be read.
The meters are supplied with connection fittings, unless they are meters with flange connections.
Functionality
The KWZ series contact water meters are multi-jet impeller meters in a fully dry-running design with magnetic coupling.
- Pulse sequence 1 pulse / 10 liters
- for horizontal installation
Advantages
Fully dry-running design with magnetic coupling
Waterproof encapsulated counter
Rotatable counter
Contact breaker easily replaceable
Contact load max. 24V, 0.2A
Scope of delivery
Contact water meter
Connection cable 2x0.75², length 3m
Water meter screw connection set (up to Qn10)
